Worcot UK Control Valve
The Worcot UK Control valves for Severe service, high pressure and temperature service valves are specially designed using the most recent refinements in control valve technology. We have used to control a wide variety of relatively clean liquids and gases at high-pressure differentials.
Severe service control valves
Features
- Designed to handle high pressure drops
- Elimination of noise
- Flow path designed to prevent blockage through flow contamination
- Trim exit velocity control
- Anti-Cavitation
- Labyrinth Disk Stack
- Hybrid Trim (Disk Stack & Hole Cage)
Applications
- Severe service application
- High pressure letdown
- Cavitation control
- Noise control
Design standard
- ASME B16.34
Pressure classes
- ASME 150 – 4500
Sizes
- 3” – 36” (80mm – 900mm)
- (other sizes under request)
Materials
- A216-WCB/WCC, A352-LCB, A217-WC6, A217-WC9, A217-C5, A217-C12, A217-C12A, A351-CF8, 351-CF3, A351-CF8M, A351-CF3M, A351-CF8C, Alloy 20, Duplex, Super Duplex, Incoloy, Monel, Inconel, Titanium, Other materials under request.
Actuator
- Spring-diaphragm
- Pneumatic Cylinder
- Electrical Motorized
- Electro-Hydraulic
Advantages
- High flow capacity and excellent flow control rangeability.
- Cage-guided construction reduces plug vibration and provides stable performance throughout travel.
- Large variation of trim designs from single stage cage to multi stage low noise/anti-cavitation trim designs.
- Quick changed trim for Easy Maintenance.
Industries
- Power Plant
- Oil & Gas
- Petrochemicals
